                                            UTL - 550M











                                                                             MINI SERIES SHRINK DISCS
                       MİNİ SERİ ŞİRİNK DİSK
         UTL - 550M ; iki konik parça, bir çember ve DIN          Locking assembly with single taper design.
                                                                  Consists of two tapered rings and a spacer. It has mini-
         931 normlarına uygun bağlantı elemanlarından             mum overall dimensions in virtue of the
         oluşmaktadır.
                                                                  reduced thickness of the cones.UTL - 550M is
                                                                  suitable for the applications where small hubs are
         Orta ve yüksek tork gerektiren yerlerde ve küçük çaplı   requested. It is recommended for mid-high torques and
         uygulamalarda önerilir.
                                                                  is self centering.

         H8-h8 Tolerans - Rt≤16µm                                 H8-h8 Tolerance - Rt≤16µm
